C5100 Advanced Water Housing for Nikon Z9

From $ 2080

Product Overview

Our C5100 Advanced Water Housing for Nikon Z9 is sold with the advanced backplate, camera tray for your camera model and the left side grip. You need to add a port system for your lens if you do not have an existing L-Port system.

The C5100 Advanced Water Housing for Nikon Z9 kit includes:

  • an extremely durable, impact resistant polyurethane resin water housing,
  • an acrylic back plate with access to your DSLR’s essential controls,
  • a rugged left side hand grip,
  • a camera tray,
  • an electronic 2 stage front shutter button,
  • our ultra-smooth zoom control*
  • 1 year warranty (see T&C for details)
  • rated to 10m/33ft depth

Our Liquid Eye Model C5100 Advanced Water Housing for Nikon Z9 is also compatible with the Canon EOS R3. All that is needed to switch from one to another is to switch the camera tray, the back plate, the camera plug (as the two cameras use different plugs) and a few others small controls specific to the camera.

* Zoom lenses require a gear sleeve to engage the water housings zoom control. These are subject to additional cost.

Product Information

Features

  • Housing made from High-strength, Durable Polyurethane resin
  • High Strength Polyurethane transparent resin Back Plate
  • Left Side Hand Grip is Ergonomic and Strong
  • Right Side Hand Grip (optional)
  • Stainless Steel Controls are Ergonomic Marine Grade Stainless
  • Lens Zoom Control Ready
  • Camera Tray System is Interchangeable
  • Electronic 2 Stage Front Shutter Control Button

Tech Specs

Size and Weight

  • Width: 210mm (8.26”)
  • Height: 203mm (7.99”)
  • Depth: 120mm (4.72”)
  • Weight: 1500g. (3.3lbs.) Housing with fully equipped backplate and left side grip.

Material

  • Polyurethane Body, Back Plate, Side Grip, Base Plate and Tray.
  • Stainless Steel and Durable Composite Controls.
  • High Strength Polyurethane Resin and Rubber Grip

Controls

On the housing

  • Electronic 2 stage front shutter button
  • Rec button control
  • ISO button control
  • AZC Zoom control
  • Mode control button
  • Flash connection port
  • GoPro Mount ready

On the Back Plate

  • Menu button control
  • i button control
  • Play button control
  • Main dial control
  • AF-on button control
  • OK button control
  • Zoom in button control
  • Zoom out button control
  • Multi-Selector (4 ways) control
  • Photo/Video selector control
  • Disp button control
  • WB button control
  • Qual button control
  • Trash (format) control
  • Soft Ergonomic Rubber Eye Cup

What’s in the Box of the C5100 Advanced Water Housing for Nikon Z9 ?

  • C5100 Water Housing with Front Shutter, Zoom Control and Electronic Cabling.
  • Camera Base Plate and Tray.
  • Back Plate with Controls.
  • Left side Grip.
  • Tool kit – 3 Hex Keys (1.5mm, 2mm, 4mm), Spare Camera Plug and ILS Switch, 2 Spare 5×16 SS Hex screws, 2 spare 5x12mm SS Flat Head Machine Screws, Packet of Marine Grease.

Color Selection

Our Water Housing stock color is yellow. Yet, we offer a wide range of color to make your model at your convenience. Select the color of your choice down below.

Due to differences with CMYK pigments colors vs RGB video colors and screen monitor settings / calibration, the real colors of the housing may differ to how they appear here. To be only used as a guide to choose the color.

For technical reasons, black and white colors are not available
